Cisco 6509 - Catalyst Chassis Switch User Manual

B-3
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix B Transceivers, Module Connectors, and Cable Specifications
Transceivers
1-GB Transceiver Modules
Table B-2 lists along with brief descriptions of the transceiver modules, pointers to cabling distances
tables, and reference illustrations.
Ta b l e B - 2 1- G B Tr a n s c e i v e r Modules Descriptions
Transceiver
Type Product Number Description
GBIC
Transceivers
WS-G5483=
• 1000BASE-T GBIC transceiver module for copper networks,
• RJ-45 connector. (See Figure B-2.)
• Transceiver cabling information is contained in Table B-3.
• Refer to your release notes for a list of compatible modules and the
software release level necessary to support this GBIC.
WS-G5484=
• 1000BASE-SX GBIC transceiver module for MMF
• 850-nm wavelength
• SC duplex connector. (See Figure B-3.)
• Transceiver cabling information is contained in Table B-3.
• Refer to your release notes for a list of compatible modules and the
software release level necessary to support this GBIC.
WS-G5486=
• 1000BASE-LX/LH GBIC transceiver module for SMF
• 1300-nm wavelength
• SC duplex connector. (See Figure B-3.)
• Transceiver cabling information is contained in Table B-3.
• Refer to your release notes for a list of compatible modules and the
software release level necessary to support this GBIC.
WS-G5487=
• 1000BASE-ZX GBIC transceiver module for SMF
• 1550-nm wavelength
• SC duplex connector. (See Figure B-3.)
• Transceiver cabling information is contained in Table B-3.
SFP
Transceivers
GLC-T=
• 1000BASE-T SFP transceiver module for copper networks
• RJ-45 connector. (See Figure B-4.)
• Transceiver cabling information is contained in Table B-4.
• Refer to your release notes for a list of compatible modules and the
software release level necessary to support this SFP.
GLC-SX-MM=
• 1000BASE-SX SFP transceiver module for MMF,
• 850-nm wavelength,
• LC duplex connector. (See Figure B-5.)
• Transceiver cabling information is contained in Table B-4.
• Refer to your release notes for a list of compatible modules and the
software release level necessary to support this SFP.
