A-27
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix A Power Supply Specifications
2500 W AC-Input and DC-Input Power Supplies
2500 W Power Supply AC Power Cords
Table A-12 lists the specifications for the AC power cords that are available for the 2500 W AC-input
power supply. The table includes references to power cord illustrations.
Note All 2500 W power supply power cords are 14 feet (4.3 meters) in length.
Note All 2500 W power supply power cords have an IEC60320/C19 appliance connector at one end.
Table A-12 2500 W Power Supply AC Power Cords
Locale
Power Cord
Part Number Source Plug Type Cordset Rating
Power Cord
Reference
Illustration
Australia, New Zealand CAB-AC-16A-AUS= AU20S3 16A,250 VAC Figure A-43
People’s Republic of
China
CAB-AC16A-CH= GB16C 16 A, 250 VAC Figure A-34
Continental Europe CAB-AC-2500W-EU= CEE 7/7 16 A, 250 VAC Figure A-38
International CAB-AC-2500W-INT= IEC 309 16 A, 250 VAC Figure A-39
Israel CAB-AC-2500W-ISRL= SI16S3 16 A, 250 VAC Figure A-31
Japan, North America
200–240VAC operation
CAB-AC-2500W-US1= NEMA 6-20
(nonlocking plug)
16 A, 250 VAC Figure A-40
Japan, North America
200–240VAC operation
CAB-AC-C6K-TWLK= NEMA L6-20
(locking plug)
16 A, 250 VAC Figure A-41
Japan, North America
100–120VAC
operation
1
1. The 2500 W power supply operating on 110 VAC delivers 1300 W.
CAB-7513AC= NEMA 5-20 20 A, 125 VAC Figure A-33
Power Distribution Unit
(PDU)
2
2. The PDU power cable is designed for users who power their switch from a PDU. The end of the cable that plugs into the Catalyst 6500 series switch
chassis has a C19 connector; the other end of the cable that plugs into the PDU has a C20 connector.
CAB-C19-CBN IEC 60320 C19
IEC 60320 C20
16 A, 250 VAC Figure A-44
Switzerland CAB-ACS-16= SEV 5934-2 Type 23 16 A, 250 VAC Figure A-42
