Appendix A Power Supply Specifications
950 W AC-Input and DC-Input Power Supplies
950 W Power Supply AC Power Cords
Table A-4 lists the 950 W AC-input power supply AC power cords specifications. These power cords
plug into the 950 W PEM(PEM-15A-AC), not directly into the power supply. The table includes
references to power cord illustrations.
Note All 950 W power supply power cords are 8 feet 2 inches (2.5 meters) in length.
Note All 950 W power supply power cords have an IEC60320/C15 appliance connector at one end. The
appliance connector has a 90° left bend.
Table A-4 950 W AC-Input Power Supply Power Cords
Locale
Power Cord
Part Number Source Plug Type Cordset Rating
Power Cord
Reference
Illustration
Australia, New Zealand CAB-AC10A-90L-AU= SAA AS 3112 10 A, 250 VAC Figure A-17
Continental Europe CAB-AC10A-90L-EU= CEE 7/7 10 A, 250 VAC Figure A-18
Italy CAB-AC10A-90L-IT= CEI 23-16/7 10 A, 250 VAC Figure A-19
Japan, North America CAB-AC15A-90L-US= NEMA 5-15 15 A, 125 VAC Figure A-20
United Kingdom CAB-AC10A-90L-UK= BS 1363
1
1. Plug contains a 13 A fuse.
10 A, 250 VAC Figure A-21
