D-1
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
APPENDIX
D
Chassis and Module Power and Heat Values
This appendix provides the power and heat numbers for the Catalyst 6500 series chassis and modules.
• Chassis and fan trays—Table D-1
• IP phones—Table D-2
• Supervisor Engine—Table D-3
• Modules—Table D-4
Unless otherwise noted, the information in the following tables is measured under fully-loaded
conditions (transceivers installed). Typical numbers are approximately 30 percent below the numbers
listed in these tables.
Note Module power is the output from the power supply (internal to the system). The AC-input power is the
input from the outlet to the power supply. The percentage difference between the two values is the
efficiency of the power supply.
Table D-1 Power Requirements and Heat Dissipation—Chassis and Fan Trays
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Catalyst 6503 chassis
FAN-MOD-3 fan tray 0.80 34.00 43.00 145.00 46.00 156.00
FAN-MOD-3HS fan tray 2.98 125.16 156.45 534.28 168.23 574.49
Catalyst 6503-E chassis
WS-C6503-E-FAN fan tray 1.37 57.54 71.93 245.62 77.34 264.11
Catalyst 6504-E chassis
FAN-MOD-4HS fan tray 1.43 60.06 75.08 256.38 80.73 275.68
Catalyst 6506 chassis
WS-C6K-6SLOT-FAN fan tray 0.71 30.00 37.48 128.00 40.00 136.88
WS-C6K-6SLOT-FAN2 fan tray 2.00 84.00 105.00 359.00 113.00 386.00
