C-2
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix C Repacking the Switch
Figure C-1 Packing Material
Figure C-2 Final Package
Note Do not use tape to hold the outside carton to the bottom pallet. Packing straps must be added to hold the
entire package together and to add strength to the package.
12984
Docs and
accessories
go in here
Top
packing
material
Power
supply(s)
go in here
12985
