Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix B Transceivers, Module Connectors, and Cable Specifications
Transceivers
10-GB Transceiver Modules
The 10-GB transceiver modules are listed in Table B-5 along with brief descriptions of the transceiver
modules, pointers to cabling distances tables, and reference illustrations.
Table B-5 10-GB Transceiver Modules
Transceiver
Type Product Number Description
XENPAK
Transceivers
XENPAK-10GB-ER=
• 10GBASE-ER XENPAK transceiver module for SMF
• 1550-nm wavelength
• SC duplex connector. (See Figure B-6.)
• Transceiver cabling information is contained in Table B-6.
• Refer to your release notes for a list of compatible modules
and the software release level necessary to support this
XENPAK transceiver.
XENPAK-10GB-LR=
• 10GBASE-LR XENPAK transceiver module for SMF
• 1310-nm wavelength
• SC duplex connector. (See Figure B-6.)
• Transceiver cabling information is contained in Table B-6.
• Refer to your release notes for a list of compatible modules
and the software release level necessary to support this
XENPAK transceiver.
XENPAK-10GB-LX4=
• 10GBASE-LX4 XENPAK transceiver module for MMF
• 1310-nm wavelength
• SC duplex connector. (See Figure B-6.)
• Transceiver cabling information is contained in Table B-6.
• Refer to your release notes for a list of compatible modules
and the software release level necessary to support this
XENPAK transceiver.
