Cisco 6509 - Catalyst Chassis Switch - 6000 W AC-Input Power Supply

A-43
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix A Power Supply Specifications
6000 W AC-Input Power Supply
6000 W AC-Input Power Supply
The 6000 W AC-input (WS-CAC-6000W) power supply is supported in the following Catalyst 6500
series switches:
• Catalyst 6506
• Catalyst 6506-E
• Catalyst 6509
• Catalyst 6509-E
• Catalyst 6509-NEB
• Catalyst 6509-NEB-A
• Catalyst 6513
The 6000 W AC-input power supply, shown in Figure A-16, shares the same form factor as the 1000 W,
1300 W, 2500 W, 3000 W, and 4000 W power supplies. The 6000 W power supply cannot be installed
in the Catalyst 6503, Catalyst 6503-E, and Catalyst 6504-E switch chassis.
Figure A-16 6000 W AC-Input Power Supply
Power
switch
Cable
retention
device
INPUT
OK
INPUT 1
100 - 240V
15A
50/60 Hz
INPUT 1
100 - 240V
15A
50/60 Hz
FAN
OK
OUTPUT
FAIL
Captive installation
screw
Status LEDs
130056
AC power
connection 2
AC power
connection 1
I
0
I
N
S
T
A
L
L
R
U
N
