A-9

Catalyst 6500 Series Switches Installation Guide

OL-5781-04

Appendix A Power Supply Specifications

1000 W AC-Input Power Supply

The 1000 W AC-input power supply (WS-CAC-1000W) is supported in the following Catalyst 6500

series switches:

• Catalyst 6506

• Catalyst 6509

• Catalyst 6509-NEB

The 1000 W power supply (shown in Figure A-4) shares the same form factor as the 1300 W, 2500 W,

3000 W, 4000 W, and 6000 W AC-input power supplies.

Figure A-4 1000 W AC-Input Power Supply

Power

switch

Cable

retention

device

AC power

connection

INPUT

FAN

OUTPUT

FAIL

Captive installation

screw

Status LEDs

16029
