Appendix A Power Supply Specifications
1300 W AC-Input and DC-Input Power Supplies
1300 W Power Supply AC Power Cords
Table A-8 lists the specifications for the AC power cords that are available for the 1300 W AC-input
power supply. The table includes references to power cord illustrations.
Note All 1300 W power supply power cords are 14 feet (4.3 meters) in length.
Note All 1300 W power supply power cords have an IEC60320/C19 appliance connector at one end.
Table A-8 1300 W Power Supply AC Power Cords
Locale
Power Cord
Part Number Source Plug Type Cordset Rating
Power Cord
Reference
Illustration
Argentina CAB-7513ACR= IRAM 2073 10 A, 250 VAC Figure A-28
Australia, New Zealand CAB-7513ACA= SAA AS 3112 15 A, 250 VAC Figure A-29
Continental Europe CAB-7513ACE= CEE 7/7 16 A, 250 VAC Figure A-30
Israel CAB-AC-2500W-ISRL= SI16S3 16 A, 250 VAC Figure A-31
Italy CAB-7513ACI= CEI 23-16/7 16 A, 250 VAC Figure A-32
Japan, North America CAB-7513AC= NEMA 5-20
1
1. For Japan, ask your local electrical contractor to prepare the NEMA 5-20 power plug.
20 A, 125 VAC Figure A-33
People’s Republic of
China
CAB-AC16A-CH= GB16C 16 A, 250 VAC Figure A-34
South Africa CAB-7513ACSA= IEC 884-1 16 A, 250 VAC Figure A-35
Switzerland CAB-ACS-10= SEV 1011 10 A, 250 VAC Figure A-36
United Kingdom CAB-7513ACU= BS 1363
2
2. Plug contains a 13 A fuse.
13 A, 250 VAC Figure A-37
