Page #52 background image
1-28
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6509 Switch
Catalyst 6509 Switch
The Catalyst 6509 switch is a 9-slot horizontal chassis. Table 1-11 lists the features of the Catalyst 6509
switch chassis. Table 1-12 lists the specifications of the Catalyst 6509 switch chassis. Figure 1-9 shows
the Catalyst 6509 switch.
Table 1-11 Catalyst 6509 Switch Features
Feature Description
Chassis
• Nine horizontal slots. Slots are numbered from 1 (top) to 9 (bottom).
Supervisor Engines
• Supports Supervisor Engine 1, Supervisor Engine 2, Supervisor
Engine 32, and Supervisor Engine 720.
–
Supervisor Engine 1 and Supervisor Engine 2 are installed in slot 1
and slot 2.
–
Supervisor Engine 32 and Supervisor Engine 720 are installed in
slot 5 and slot 6.
–
Supervisor Engine 32 and Supervisor Engine 720 require that you
install the high-speed fan tray. You must also install a 2500 W or
higher capacity power supply in the chassis to power the high-speed
fan tray.
Note The 2500 W power supply, when supporting the high-speed fan
tray, can be powered from either 120 VAC or 220 VAC.
–
Supervisor Engine 720 has built-in switching fabric. Switch Fabric
Modules are not supported by Supervisor Engine 720 and cannot be
installed in the same chassis.
• The uplink ports are fully functional on all redundant supervisor engine
models when they are in standby mode.
Note Redundant supervisor engines must be configured identically.
Modules
• Supports up to eight Catalyst 6500 series modules.
• WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be
installed in slot 5 or slot 6.
• Some Catalyst 6500 series modules may:
–
Not be supported
–
Require that you install a Supervisor Engine 720
–
Have chassis slot restrictions
–
Require a specific software release level
Check your software release notes for specific information.
Backplane Bandwidth
• 32 GBps shared bus.
• 256 GBps switch fabric.
• 720 GBps switch fabric.
