A-42
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix A Power Supply Specifications
4000 W AC-Input and DC-Input Power Supplies
4000 W Power Supply AC Power Cords
Table A-18 lists the specifications for the AC power cords that are available for the 4000 W AC-input
power supply. Included in the table are references to illustrations of the power cords.
Table A-18 4000 W Power Supply AC Power Cords
Locale
Power Cord
Part Number
1
1. This the part number for the power supply. The AC power cords are hardwired to the 4000 W power supplies.
Source Plug Type Cordset Rating
Power Cord
Reference
Illustration
International WS-CAC-4000W-INT= IEC 60309 32 A, 250 VAC Figure A-45
North America, Japan WS-CAC-4000W-US= NEMA L6-30
2
2. For Japan, ask your local electrical contractor to prepare the NEMA L6-30 power plug.
30 A, 250 VAC Figure A-46
