A-41
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix A Power Supply Specifications
4000 W AC-Input and DC-Input Power Supplies
Power supply output (AC power supply) • 15 A @ +3.3 V
• 5A @ +5V
• 10 A @ +12 V
• 90.36 A @ +42 V
Power supply output (DC power supply)
• 15 A @ + 3.3 VDC
• 5A @ + 5 VDC
• 12 A @ +12 VDC
• 90.63 A (three inputs) or 59.68 A (two inputs)
@ +42 VDC
Note The 4000 W power supply cannot operate with
only one source DC-input connected.
DC input terminal block Accepts 4 AWG copper conductors. Actual size of the
wire needed is determined by the installer or local
electrician.
Output holdup time
• 20 ms minimum (AC-input power supply)
• 8 ms (DC-input power supply)
Heat Dissipation
• 17,065 BTU/hour (approx.) AC-input power
supply
• 17,730 BTU/hour (approx.) DC-input power
supply
Front panel LEDs
• INPUT OK AC-input power supplies:
• Green—Source AC voltage is OK. (Input voltage
is 85 VAC or greater.)
• Off—Source AC voltage falls below 70 VAC, is
not present, or the power supply is turned off.
DC-input power supplies:
• Green—Source DC voltage is OK. (Input voltage
is –40.5 VDC or greater.)
• Off—Source DC voltage falls below –33 VDC, is
not present, or the power supply is turned off.
• FAN OK • Green—Power supply fan is operating properly.
• Off—Power supply fan failure is detected.
• OUTPUT FAIL • Red—Problem with one or more of the DC-output
voltages of the power supply.
• Off—DC-output voltages within acceptable
margins.
Weight AC-input—22.2 lb (10.1 kg)
DC-input—30.8 lb (14.0 kg)
Table A-17 4000 W AC-Input and DC-Input Power Supplies Specifications (continued)
Specification Description
