B-7
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix B Transceivers, Module Connectors, and Cable Specifications
Transceivers
Figure B-4 1000BASE-T SFP Transceiver Module (GLC-T)
Figure B-5 1000BASE-X SFP Transceiver Modules (GLC-SX-MM, GLC-LH-SM, and GLC-ZX-SM)
Note You can use any combination of SFP modules that your Cisco device supports. The only restrictions are
that each SFP port must match the wavelength specifications on the other end of the cable and that the
cable must not exceed the stipulated cable length for reliable communications.
87922
114944
