B-6
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix B Transceivers, Module Connectors, and Cable Specifications
Transceivers
Figure B-2 1000BASE-T GBIC Transceiver Module (WS-G5483)
Figure B-3 1000BASE-X GBIC Transceiver Modules (WS-G5484, WS-G5486, and WS-G5487)
Table B-4 SFP Transceiver Module Cabling Specifications
SFP Module Connector
Wavelength
(nm) Fiber Type
Core Size
(micron)
Modal
Bandwidth
(MHz/km) Cable Distance
1000BASE-T
(GLC-T=)
RJ-45 — Category 5,
5e, or 6
UTP/FTP
—— 328ft (100m)
1000BASE-SX
(GLC-SX-MM=)
LC duplex 850 MMF 62.5
62.5
50.0
50.0
160
200
400
500
722 ft (220 m)
902 ft (275 m)
1640 ft (500 m)
1804 ft (550 m)
1000BASE-LX/LH
(GLC-LH-SM=)
LC duplex 1300 MMF
1
SMF
1. A mode-conditioning patch cord is required. Using an ordinary patch cord with MMF, 1000BASE-LX/LH SFP modules, and a short link distance
can cause transceiver saturation, resulting in an elevated bit error rate (BER). When using the LX/LH SFP module with 62.5-micron diameter
MMF, you must also install a mode-conditioning patch cord between the SFP module and the MMF cable on both the sending and receiving ends
of the link. The mode-conditioning patch cord is required for link distances greater than 984 ft (300 m).
62.5
50.0
50.0
G.652
500
400
500
—
1804 ft (550 m)
1804 ft (550 m)
1804 ft (550 m)
6.21 mi (10 km)
1000BASE-ZX
(GLC-ZX-SM=)
LC duplex 1550 SMF G.652 — 43.4 to 62 mi (70 to
100 km)
2
2. 1000BASE-ZX SFP modules can reach up to 100 km by using dispersion-shifted SMF or low-attenuation SMF; the distance depends on the fiber
quality, the number of splices, and the connectors.
RJ-45
connector
Plastic tab
49959
36494
Receiver Transmitter
