D-2
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
The module power values listed in Table D-3 and Table D-4 are based on 42 VDC. Power is distributed
to each slot in the chassis from the power supply’s 42 VDC output. Each module has DC-to-DC power
supplies that convert the 42 VDC into +2.5 VDC, +3.3 VDC, and +5 VDC to power the module. The
42 VDC is independent of the power supply’s input voltage, either 110 VAC or 220 VAC.
Catalyst 6506-E chassis
WS-C6506-E-FAN fan tray 2.35 98.70 123.40 421.33 132.66 453.04
Catalyst 6509 chassis
WS-C6K-9SLOT-FAN fan tray 1.10 46.00 58.00 196.00 62.00 212.00
WS-C6K-9SLOT-FAN2 fan tray 3.04 127.68 159.60 545.03 171.70 586.06
Catalyst 6509-E chassis
WS-C6509-E-FAN fan tray 3.58 150.00 188.00 642.00 202.00 690.00
Catalyst 6509-NEB chassis
WS-C6K-NEB-FAN fan tray 7.00 294.00 368.00 1255.00 395.00 1349.00
Catalyst 6509-NEB-A chassis
FAN-MOD-09
1
fan tray 5.75 242.00 302.00 1031.00 325.00 1108.00
Catalyst 6513 chassis
WS-C6K-13SLOT-FAN fan tray 1.58 73.00 146.00 499.00 157.00 536.00
WS-C6K-13SLOT-FAN2 fan tray 7.10 298.20 372.75 1272.94 400.81 1368.75
1. Values given are per fan tray. The Catalyst 6509-NEB-A switch chassis ships with one fan tray installed by default. A second fan tray can be
installed in the chassis. The power and heat numbers for a chassis equipped with two fan trays are double the values listed.
Table D-2 Power Requirements and Heat Dissipation—IP Phones
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Cisco IP Phone 7960 0.15 6.3 7.88 26.89 8.47 28.92
Cisco IP Phone 7940 0.15 6.3 7.88 26.89 8.47 28.92
Cisco IP Phone 7910 0.13 5.46 6.83 23.31 7.34 25.06
Table D-1 Power Requirements and Heat Dissipation—Chassis and Fan Trays (continued)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
