Appendix A Power Supply Specifications
950 W AC-Input and DC-Input Power Supplies
Front panel LEDs
• INPUT OK AC-input power supplies:
• Green—Source AC voltage is OK. (Input voltage
is 85 VAC or greater.)
• Off—Source AC voltage falls below 70 VAC, is
not present, or the PEM is turned off.
DC-input power supplies:
• Green—Source DC voltage is OK. (–40.5 VDC or
greater.)
• Off—Source DC voltage falls below –33 VDC or
is not present at the PEM.
• FAN OK Green—Power supply fan is operating properly.
Off—Power supply fan failure is detected.
• OUTPUT FAIL Red—Problem with one or more of the DC-output
voltages of the power supply is detected.
Off—DC-output voltages within acceptable margins.
Weight
• AC-input—8.2 lb (3.7 kg)
• DC-input—8.4 lb (3.8 kg)
Table A-3 950 W AC-Input and DC-Input Power Supplies Specifications (continued)
Item Specification

Cisco 6509 - Catalyst Chassis Switch Specifications

General

Brand	Cisco
Model	6509 - Catalyst Chassis Switch
Category	Switch
Language	English
