Cisco 6509 - Catalyst Chassis Switch User Manual

4-24
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 4 Removal and Replacement Procedures
Removing and Installing the DC-Input Power Supplies
Figure 4-16 DC-Input Power Supply Connectors (WS-CDC-1300W)
Figure 4-17 DC-Input Power Supply Connectors (WS-CDC-2500W)
INPUT
OK
FAN
OK
OUTPUT
FAIL
I
0
18736
Power leads attached
to terminal block
(+) Positive
( - ) Negative
( ) Ground
Captive
installation
screw
DC-input power supply
with the terminal block
cover removed
Power
switch
DC-input cable
INPUT
OK
FAN
OK
OUTPUT
FAIL
I
0
85907
Power leads
attached to
terminal block
( - ) Negative
(+) Positive
( ) Ground
Captive
installation
screw
Power
switch
DC-input cable
