A-3
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix A Power Supply Specifications
Power Supply Compatibility Matrix
Catalyst 6509-E • 2500 W AC-input and DC-input
• 3000 W AC-input
• 4000 W AC-input and DC-input
• 6000 W AC-input
Catalyst 6509-NEB
• 1000 W AC-input
• 1300 W AC-input and DC-input
• 2500 W AC-input and DC-input
• 3000 W AC-input
• 4000 W AC-input and DC-input
• 6000 W AC-input
4
Catalyst 6509-NEB-A • 2500 W AC-input and DC-input
• 3000 W AC-input
• 4000 W AC-input and DC-input
• 6000 W AC-input
4
Catalyst 6513 • 2500 W AC-input and DC-input
• 3000 W AC-input
• 4000 W AC-input and DC-input
• 6000 W AC-input
1. Requires a PEM-15A-AC Power Entry Module (PEM).
2. Requires a PEM-DC/3 Power Entry Module (PEM).
3. Requires a PEM-20A-AC+ Power Entry Module (PEM).
4. In this chassis, the 6000 W power supply operates at a 4000 W maximum
output.
Table A-2 Catalyst 6500 Series Switch Supported Power Supply Configurations (continued)
Platform Supported Power Supplies
To Next Page
