Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6503 Switch
Fan Tray • Supports one hot-swappable fan tray. These fan tray models are
supported:
– FAN-MOD-3 (Standard fan tray—170 CFM). Supports Supervisor
Engine 1 and Supervisor Engine 2 only; does not support
Supervisor Engine 32 or Supervisor Engine 720.
– FAN-MOD-3HS (Optional high-speed fan tray—270 CFM).
Required for Supervisor Engine 32 and Supervisor Engine 720.
Supports Supervisor Engine 1 and Supervisor Engine 2.
Note Both fan tray models contain four individual fans. The
individual fans are not field replaceable. You must replace the
fan tray.
Note The WS-C6503-E-FAN tray is not supported in the
Catalyst 6503 chassis.
• Fan tray STATUS LED
– Red—One or more individual fans have failed.
– Green—Fan tray is operating normally.
Table 1-1 Catalyst 6503 Switch Features (continued)
Feature Description
