1-25
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6506-E Switch
Fan Tray • Supports one hot-swappable fan tray. These fan tray models are
supported:
– WS-C6506-E-FAN—564 CFM
Note You must install a 2500 W or higher capacity power supply in
the chassis to power the fan tray. The 2500 W power supply can
be powered from either 120 VAC or 220 VAC.
Note The fan tray contains six individual fans. The individual fans are
not field replaceable. You must replace the fan tray.
• Fan tray STATUS LED
– Red—One or more individual fans have failed.
– Green—Fan tray is operating normally.
Power Supply
• Supports one or two power supplies. The following power supplies are
supported:
– WS-CAC-2500W (2500 W AC-input power supply).
– WS-CDC-2500W (2500 W DC-input power supply).
– WS-CAC-3000W (3000 W AC-input power supply).
– WS-CAC-4000W-US (4000 W AC-input power supply).
– WS-CAC-4000W-INT (4000 W AC-input power supply).
– PWR-4000-DC (4000 W DC-input power supply).
– WS-CAC-6000W (6000 W AC-input power supply).
• Installed power supplies can be of different wattage ratings. Installed
power supplies can also be both AC-input, both DC-input, or one
AC-input and one DC-input. Power supplies can be configured in either
redundant or non-redundant mode.
• All Catalyst 6500 series AC-input power supplies require single-phase
source AC. Source AC can be out of phase between multiple power
supplies or multiple AC-power plugs on the same power supply because
all AC power supply inputs are isolated.
• Single power supplies are installed in the left power supply bay. The
second power supply is installed in the right power supply bay.
Table 1-9 Catalyst 6506-E Switch Features (continued)
Feature Descriptions
