1-30
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6509 Switch
Power Supply • Supports one or two power supplies. The following power supply
models are supported:
– WS-CAC-1000W (1000 W AC-input power supply).
– WS-CAC-1300W (1300 W AC-input power supply).
– WS-CDC-1300W (1300 W DC-input power supply).
– WS-CAC-2500W (2500 W AC-input power supply).
– WS-CDC-2500W (2500 W DC-input power supply).
– WS-CAC-3000W (3000 W AC-input power supply).
– WS-CAC-4000W-US (4000 W AC-input power supply).
– WS-CAC-4000W-INT (4000 W AC-input power supply).
– PWR-4000-DC (4000 W DC-input power supply).
– WS-CAC-6000W (6000 W AC-input power supply)
1
.
• Installed power supplies can be of different wattage ratings. Installed
power supplies can also be both AC-input, both DC-input, or one
AC-input and one DC-input. Power supplies can be configured in either
redundant or non-redundant mode.
• All Catalyst 6500 series AC-input power supplies require single-phase
source AC. Source AC can be out of phase between multiple power
supplies or multiple AC-power plugs on the same power supply because
all AC power supply inputs are isolated.
• Single power supplies are installed in the left power supply bay. The
second (redundant) power supply is installed in the right power supply
bay.
• You must install a 2500 W or higher capacity power supply when using
the Supervisor Engine 32 or the Supervisor Engine 720 and the
high-speed fan tray.
1. When installed in a Catalyst 6509 switch chassis, the 6000 W power supply has a maximum output of 4000 W.
Table 1-11 Catalyst 6509 Switch Features (continued)
Feature Description
