1-37
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6509-E Switch
Physical Characteristics
Dimensions (H x W x D) • 24.5 x 17.5 x 18.2 in. (62.2 x 44.5 x 46.0 cm).
• Chassis depth including cable guide is 21.64 in. (55.0 cm).
• Chassis requires 15 RU
1
.
• The Catalyst 6509-E switch chassis is designed to install in standard
19-inch equipment racks that meet ANSI/EIA 310-D, IEC 60297, and
ETS 300-119 standards.
Weight Chassis only: 60 lb (27.3 kg).
Chassis fully configured with 1 supervisor engine, 8 switching modules, and
2 power supplies: 190 lb (86.4 kg).
Airflow
WS-C6509-E-FAN—846 CFM
Note To maintain proper air circulation through the Catalyst switch
chassis, we recommend that you maintain a minimum 6-inch
(15 cm) separation between a wall and the chassis air intake or a wall
and the chassis air exhaust. You should also allow a minimum
separation of 12 inches (30.5 cm) between the hot air exhaust on one
chassis and the air intake on another chassis. Failure to maintain
adequate air space can cause the chassis to overheat and the system
to fail. On Catalyst chassis in which the airflow is from front to back,
the chassis may be placed side-by-side.
1. RU = rack units
Table 1-14 Catalyst 6509-E Switch Specifications (continued)
Item Specification
