Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6509-NEB Switch
Physical Characteristics
Dimensions (H x W x D) • 33.3 x 17.2 x 18.1 in. (84.6 x 43.7 x 46.0 cm).
• Chassis requires 20 RU
1
.
• The Catalyst 6509-NEB switch chassis is designed to install in standard
19-inch equipment racks that meet ANSI/EIA 310-D, IEC 60297, and
ETS 300-119 standards.
Weight Chassis only: 55 lb (24.9 kg).
Chassis fully configured with 1 supervisor engine, 8 switching modules, and
2 power supplies: 135 lb (61.2 kg).
Airflow
•
WS-C6509-NEB-FAN (Standard fan tray)—294 CFM
• Optional high-speed fan tray
2
—630 CFM
Note To maintain proper air circulation through the Catalyst switch
chassis, we recommend that you maintain a minimum 6-inch
(15 cm) separation between a wall and the chassis air intake or
a wall and the chassis air exhaust. You should also allow a
minimum separation of 12 inches (30.5 cm) between the hot air
exhaust on one chassis and the air intake on another chassis.
Failure to maintain adequate air space can cause the chassis to
overheat and the system to fail. On Catalyst chassis in which the
airflow is from front to back, the chassis may be placed
side-by-side.
1. RU = rack units.
2. Part of the WS-6509-NEB-UPGRD kit.
Table 1-16 Catalyst 6509-NEB Switch Specifications (continued)
Item Specification
