3.5 mm jack for microphone and speaker connection (for Cisco Unified IP Phone 7971G-GE and 7970G
only).
•
48-volt power connector.
Network and Access Port Pinouts
Although both the network and access ports are used for network connectivity, they serve different purposes
and have different port pinouts. The access port is also known as the computer port.
Network Port Connector
The following table describes the network port connector pinouts.
Table 60: Network Port Connector Pinouts
FunctionPin number
BI_DA+1
BI_DA-2
BI_DB+3
BI_DC+4
BI_DC-5
BI_DB-6
BI_DD+7
BI_DD-8
BI stands for bidirectional, while DA, DB, DC and DD stand for Data A, Data B, Data C and Data
D respectively.
Note
Computer Port Connector
The following table describes the computer port connector pinouts.
Table 61: Computer (Access) Port Connector Pinouts
FunctionPin number
BI_DB+1
Cisco Unified IP Phone 7975G, 7971G-GE, 7970G, 7965G, and 7945G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
261
Technical Specifications
Network and Access Port Pinouts

Cisco 7975G Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Grey, Silver
Speakerphone	Yes
Voice codecs	G.711Mu, G.711a, G.722, G.729A, iLBC
Number of melodies	24
Aspect ratio	4:3
Display diagonal	5.6 \
Display resolution	320 x 240 pixels
Lines quantity	8 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Front camera	No
Security algorithms	128-bit AES
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	DHCP, TFTP
Volume control	Digital
Headphone outputs	1
Ethernet LAN (RJ-45) ports	2
Number of handles included	1 pc(s)
AC adapter output voltage	48 V
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	FCC

Weight and Dimensions

Depth	152.4 mm
Width	266.7 mm
Height	203.2 mm
Weight	1600 g
