PurposeCommand or Action
Enters the satellite network virtualization (nV) configuration
submode.
nv
Example:
RP/0/RSP0/CPU0:router(config-if)# nv
Step 12
Specifies an interface as an Interface Control Plane
Extender(ICPE) inter-chassis link (ICL).
satellite-fabric-link network satellite satellite_id
Example:
RP/0/RSP0/CPU0:router(config-if-nV)#
satellite-fabric-link network satellite 100
Step 13
The Interface Control Plane Extender(ICPE)
infrastructure has a mechanism to provide the Control
Plane of an interface physically located on the
Satellite device in the local Cisco IOS XR software.
Note
Configures the remote satellite ports 0 to 5. Enters the SFL
network satellite configuration mode.
remote-ports interface_type remote_subslot
Example:
RP/0/RSP0/CPU0:router(config-sfl-network-sat)#
remote-ports GigabitEthernet 0/0/0-4
Step 14
Attaches a policy map to an output interface to be used as the
service policy for that interface.
service-policy output policy-map
Example:
RP/0/RSP0/CPU0:router(config-sfl-network-sat)#
service-policy output policy6
Step 15
Returns the router to nV configuration mode.exit
Example:
RP/0/RSP0/CPU0:router(config-sfl-network)# exit
Step 16
Specifies an interface as an Interface Control Plane
Extender(ICPE) inter-chassis link (ICL).
satellite-fabric-link network satellite satellite_id
Example:
RP/0/RSP0/CPU0:router(config-if-nV)#
satellite-fabric-link network satellite 200
Step 17
The Interface Control Plane Extender(ICPE)
infrastructure has a mechanism to provide the Control
Plane of an interface physically located on the
Satellite device in the local Cisco IOS XR software.
Note
Configures the remote satellite ports 5 to 9. Enters the SFL
network satellite configuration mode.
remote-portsinterface_type remote_subslot
Example:
RP/0/RSP0/CPU0:router(config-sfl-network-sat)#
remote-ports GigabitEthernet 0/0/5-9
Step 18
Attaches a policy map to an output interface to be used as the
service policy for that interface.
service-policy output policy-map
Example:
RP/0/RSP0/CPU0:router(config-sfl-network-sat)#
service-policy output policy6
Step 19
commit
Step 20
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
94
Configuring QoS on the Satellite System
Offloading Service-policy on Ring Physical SFL
