Log
The ATA allows you to record incoming, outgoing, and DHCP lists for various events that occur on your
network. The Incoming Log displays a temporary list of the source IP addresses and destination port numbers
for the incoming Internet traffic. The Outgoing Log displays a temporary list of the local IP addresses,
destination URLs/IP addresses, and service/port numbers for the outgoing Internet traffic.
Debug Log Module
Use the Administration > Log Module > Debug Log Module page to enable and configure logging.
As a best practice, we recommend that you enable logging only when needed, and disable logging when
you finish the investigation. Logging consumes resources and can impact system performance.
In this page, you can select the modules which you want to see debug messages in all severity levels.
Debug Log Setting
If Debug Log Server is enabled on the Administration > Log > Debug Log Server page, the ATA will send
the debug messages to one server.
Enter the settings as described below. After making changes, click Submit to save your settings, or click
Cancel to redisplay the page with the saved settings.
Table 73: Debug Log Setting
DescriptionField
Enter the maximum size of the log file in kilobytes. Valid values are
from 128 to 1024.
Debug Log Size
Enter the IPv4 address of the debug log server where the messages will
be sent.
IPv4 Address
Enter the IPv6 address of the debug log server where the messages will
be sent.
IPv6 Address
Enter the port to use on the server. Valid values are from 1 to 65535.Port
Debug Log Viewer
If logging is enabled on the Administration > Log > Debug Log Viewer page, you can use the Log Viewer
page view the logs online and to download the system log file to your computer. You can limit the contents
of the log by choosing the types of entries to include and by specifying keywords.
Note For information about enabling and configuring logging, see Debug Log Module, on page 102.
Cisco ATA 191 and ATA 192 Analog Telephone Adapter Administration Guide for Multiplatform Firmware
102
Administration Settings
Log
