Cisco ATA 192 Administration Guide

Miscellaneous
Table 46: Miscellaneous Settings
DescriptionField
Sets the electrical impedance of the PHONE port.
Choices are:
•
600
•
900
•
600+2.16uF
•
900+2.16uF
•
220+850||120nF
•
220+820||115nF
•
200+600||100nF
Default setting: 600.
FXS Port Impedance:
Input gain in dB, up to three decimal places. The
range is 6.000 to -12.000.
Default setting: -3.
FXS Port Input Gain:
Output gain in dB, up to three decimal places. The
range is 6.000 to -12.000. The Call Progress Tones
and DTMF playback level are not affected by the FXS
Port Output Gain parameter.
Default setting: -3.
FXS Port Output Gain:
Local DTMF playback level in dBm, up to one
decimal place.
Default setting: -16.0.
DTMF Playback Level:
To gain difference between the two tone frequency.
Default setting: 2
DTMF Twist:
Local DTMF playback duration in milliseconds.
Default setting: .1.
DTMF Playback Length:
Cisco ATA 191 and ATA 192 Analog Telephone Adapter Administration Guide for Multiplatform Firmware
70
Voice Settings Configuration
Miscellaneous

Cisco ATA 192 Specifications

General

Ports	2 FXS ports
Network Interface	10/100 Ethernet
Voice Protocol	SIP
Audio Codecs	G.711, G.726, G.729
Operating Temperature	0 to 40°C (32 to 104°F)
Storage Temperature	-20 to 60°C (-4 to 140°F)
Humidity	10 to 90% non-condensing
Compliance	FCC, CE, UL
Fax Support	T.38, G.711 pass-through
