DescriptionField
This parameter has three possible values:
•
caller or callee: The ATA will detect FAX tone whether it is callee
or caller
•
caller only: The ATA will detect FAX tone only if it is the caller
•
callee only: The ATA will detect FAX tone only if it is the callee
Default setting: caller or callee.
FAX Tone Detect Mode
Enable symmetric RTP operation. If enabled, the ATA sends RTP
packets to the source address and port of the last received valid inbound
RTP packet. If disabled (or before the first RTP packet arrives) the ATA
sends RTP to the destination as indicated in the inbound SDP.
Default setting: no
Symmetric RTP
When this feature is enabled, upon completion of the fax image transfer,
the connection remains established and reverts to a voice call using the
previously designated codec. Select yes to enable this feature, or select
no to disable it.
Default setting: no
Fax T38 Return to Voice
Enable an alternate method to make the modem call without Modem
Line Toggle Code pre-dialing.
Default setting: no
Modem Line
Enable to send RTP to proxy when line is held by remote side.
Default setting: no
RTP to Proxy in Remote Hold
Dial Plan
The default dial plan script for the line is as follows:
(*xx|[3469]11|0|00|[2-9]xxxxxx|1xxx[2-9]xxxxxx|xxxxxxxxxxxx.)
Each parameter is separated by a semi-colon (;)
Example 1:
*1xxxxxxxxxx<:@fwdnat.pulver.com:5082;uid=jsmith;pwd=xy z
Example 2:
*1xxxxxxxxxx<:@fwd.pulver.com;nat;uid=jsmith;pwd=xyz
The syntax for a dial plan expression is described in the table below.
Cisco ATA 191 and ATA 192 Analog Telephone Adapter Administration Guide for Multiplatform Firmware
87
Voice Settings Configuration
Dial Plan
