Cisco Catalyst 6500 Series Installation Guide

2-5
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
Chapter 2 Preparing for Installation
Determining Cable Distances
Gigabit Ethernet
Table 2-6 provides the maximum transmission distance specifications for the
1000BASE-T and the 1000BASE-X interfaces, including the Gigabit Ethernet
switching modules and the supervisor engine Gigabit Ethernet uplink ports.
Table 2-7 lists the Gigabit Interface Converter (GBIC) channel insertion losses.
All optical GBIC interfaces have SC connectors, and the minimum cable distance
for the optical GBICs listed (MMF and SMF) is 6.5 feet (2 meters).
Table 2-5 100BASE-FX Optical Characteristics
Characteristic Specification (Multimode) Specification (Single Mode)
Optical source LED Laser
Wavelength 1300 nm 1300 nm
Transmitter output power –20 to –14 dBm (62.5/125 micron MMF)
–23.5 to –14 dBm (50/125 micron MMF)
–20 to –14 dBm
(8.3/9/10 micron SMF)
Receiver sensitivity –31 to –14 dBm –31 to –8 dBm
