Chapter 1 Product Overview
10/100 and 10/100/1000 Ethernet Switching Modules
1-20
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
24-Port 10BASE-FL Ethernet Switching Module
(WS-X6024-10FL-MT)
The 24-port 10BASE-FL switching module (WS-X6024-10FL-MT) provides 24
switched, 10-Mbps, full- or half-duplex ports. (See Figure 1-4.) The module has
24 MT-RJ connectors for connection to multimode fiber-optic (MMF) cable.
The QoS port architecture (Rx/Tx) for this module is 1q4t/2q2t.
Note This module is a Class 1 laser product. Refer to the Regulatory Compliance and
Safety Information for the Catalyst 6500 Series Switches for information on
working with lasers.
Figure 1-4 24-Port 10BASE-FL Ethernet Switching Module (WS-X6024-10FL-MT)
The front panel LEDs are described in Table 1-6 on page 1-47.
24 PORT 10FL
WS-X6024-10FL-MT
S
T
A
T
U
S
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
L
IN
K
26947
