Cisco Catalyst 6500 Series Installation Guide

Chapter 2 Preparing for Installation
Gigabit Interface Converters
2-24
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
CWDM SFP Optical Transceiver Modules
The Coarse Wavelength Division Multiplexing (CWDM) SFPs are hot-swappable,
transceiver components that you can plug into standard receptacles in switching
modules that convert Gigabit Ethernet electrical signals into a single-mode
fiber-optic (SMF) interface. You can connect the CWDM SFPs to CWDM passive
optical system optical add/drop multiplexer (OADM) modules or
multiplexer/demultiplexer plug-in modules using single-mode fiber-optic cables
with standard SC connectors. Table 2-15 lists the available CWDM SFP
wavelengths and color-coding identifier.
Figure 2-14 shows a CWDM SFP with the optical port dust plug removed.
Table 2-15 CWDM SFP Optical Transceiver Models
CWDM SFP Product
Number Wavelength Color
CWDM-SFP-1470 Longwave 1470 nm laser, single mode Gray
CWDM-SFP-1490 Longwave 1490 nm laser, single mode Violet
CWDM-SFP-1510 Longwave 1510 nm laser, single mode Blue
CWDM-SFP-1530 Longwave 1530 nm laser, single mode Green
CWDM-SFP-1550 Longwave 1550 nm laser, single mode Yellow
CWDM-SFP-1570 Longwave 1570 nm laser, single mode Orange
CWDM-SFP-1590 Longwave 1590 nm laser, single mode Red
CWDM-SFP-1610 Longwave 1610 nm laser, single mode Brown
