Cisco Catalyst 6500 Series Installation Guide

Chapter 1 Product Overview
FlexWAN Module (WS-X6182-2PA)
1-52
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
FlexWAN Module (WS-X6182-2PA)
The FlexWAN module (WS-X6182-2PA) is installed in a switch that has a
supervisor engine with an MSFC and a PFC. (See Figure 1-39.) The MSFC, in
conjunction with the FlexWAN module, provides multiprotocol routing support
with full Internet route connectivity for speeds ranging from serial RS-232 to
OC-3. The FlexWAN module can accept up to two Cisco 7200/7500 WAN port
adapters, which deliver WAN consolidation and extend QoS and
traffic-management capabilities over WAN segments. The FlexWAN module
supports ATM and Packet-over-SONET (POS) OC-3 links and channelized,
multichannel, and clear channel port adapters. Table 1-8 lists the supported
adapters.
LINK Green The port is active (the link is connected and operational).
Orange The module or port is disabled through the CLI command or the module
is initializing.
Flashing
orange
The port is faulty and has been disabled.
Off The port is not active or the link is not connected.
ACTIVE Green The port is active (the link is connected and operational).
Off The port is the standby port.
SIGNAL Green The active port is receiving a valid signal level through the fiber-optic
cable; this condition does not indicate valid framing.
Table 1-7 ATM Module LEDs (continued)
LED Color/State Description
