Cisco Catalyst 6500 Series Installation Guide

B-1
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
APPENDIX
B
Cable and Connector Specifications
This appendix lists the cable and connector specifications for the Catalyst 6500
series modules. The following connectors and signal summaries are contained in
this appendix:
• RJ-21 Connector, page B-2
• RJ-21 (WS-X6624-FXS Only), page B-4
• RJ-45 Connector, page B-5
• Supervisor Engine Console Port Signals and Pinouts, page B-8
• Fiber-Optic Connectors, page B-14
