Cisco Catalyst 6500 Series Installation Guide

1-47
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
Chapter 1 Product Overview
Ethernet Module LEDs
The front panel LEDs are described in Table 1-6 on page 1-47.
Ethernet Module LEDs
The Ethernet and Gigabit Ethernet module front-panel LEDs are described in
Table 1-6.
Table 1-6 Ethernet and Gigabit Ethernet Module LEDs
LED Color/State Description
STATUS Green All diagnostics pass; the module is operational.
Orange The module is booting or running diagnostics.
An overtemperature condition has occurred. (A minor temperature
threshold has been exceeded during environmental monitoring.)
Red The module is resetting. The switch has just been powered on or the
module has been hot inserted during the normal initialization
sequence.
An overtemperature condition has occurred. (A major temperature
threshold has been exceeded during environmental monitoring.)
If the module fails to download code and configuration information
successfully during the initial reset, the LED stays red; the module
does not come online.
Off The module is not receiving power.
