1-53
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
Chapter 1 Product Overview
FlexWAN Module (WS-X6182-2PA)
For more information about the MSFC and PFC, refer to the Catalyst 6500 Series
Switch Software Configuration Guide.
Note Throughout this publication, except where noted, the term MSFC refers to both
MSFC and MSFC2, and the term PFC refers to both PFC and PFC2.
Note To use the FlexWAN module, you must have a supervisor engine with an MSFC
and a PFC. You configure the FlexWAN module through the MSFC.
The STATUS LED on the FlexWAN module front panel (see Figure 1-39)
indicates the status of the FlexWAN module. Table 1-9 describes the LED
operation.
For information on FlexWAN module hardware and software requirements and
port adapter installation and configuration, refer to the Catalyst 6000 Family
FlexWAN Module Installation and Configuration Note.
Table 1-8 WS-X6182-2PA Supported Cisco 7200 Series and Cisco 7500 Series
WAN Port Adapters
T1/E1 T3/E3 and STM-1 HSSI ATM Packet over SONET
PA-4T+ PA-T3 PA-H PA-A3-T3 PA-POS-OC3MM
PA-8T-V35 PA-T3+ PA-2H PA-A3-E3 PA-POS-OC3SMI
PA-8T-232 PA-E3 PA-A3-OC3MM PA-POS-OC3SML
PA-8T-X21 PA-2T3 PA-A3-OC3SMI
PA-MC-4T1 PA-2T3+ PA-A3-OC3SML
PA-MC-8T1 PA-2E3
PA-MC-8E1/120 PA-MC-T3
PA-MC-E3
PA-MC-STM-1
