Cisco Catalyst 6500 Series Installation Guide

1-3
Catalyst 6500 Series Switch Module Installation Guide
78-15725-02
Chapter 1 Product Overview
Catalyst 6000 Series Switches
Note The uplink ports are fully functional on the redundant supervisor engine in
standby mode.
The Catalyst 6000 series switches support the following hardware:
• A supervisor engine with two gigabit interface uplinks and an optional
redundant supervisor engine
Note Supervisor Engine 720 is not supported in the Catalyst 6006 and
Catalyst 6009 switches.
Both supervisor engines in a single chassis must be completely identical. You
can configure the redundant supervisor engines in a Catalyst 6000 series
switch in one of three configurations:
– Two supervisor engines, each with no Multilayer Switch Feature Card
(MSFC) and no Policy Feature Card (PFC)
– Two supervisor engines, each configured with a PFC daughter card
– Two supervisor engines, each configured with both an MSFC and a PFC
daughter card
• Additional switching modules (Ethernet, Fast Ethernet, Gigabit Ethernet, and
ATM) in any combination
– Five additional switching modules in the Catalyst 6006
– Eight additional switching modules in the Catalyst 6009
Note The Switch Fabric Modules are not supported in the
Catalyst 6000 series switches.
• Hot-swappable fan assembly and modules
• Redundant AC-input or DC-input power supplies
• Backplane bandwidth of 32 Gbps
