CardsSubmenu Item 2Submenu Item 1Card GroupSubmenu
Category
Menu Item
OSCM (Slots 8
and 10 only)
———
—OSCM
TNC, TNCE,
TSC, TSCS, and
TNCS/TNCS-O
——Control Cards—TNC TSC
Choose the menu option TNC for TNC, TNCE, or TNCS/TNCS-O pre-provision. The CTC displays
the TNC, TNCE, or TNCS/TNCS-O card name according to the inserted card. Same applies for
TSC card also.
Note
When you pre-provision a slot, the card appears purple in the CTC shelf graphic (the card appears
as white when a card is installed in the slot). NP on the card graphic indicates that the card is not
physically installed.
Note
Step 3 Repeat Step 2 until all the cards shown in the Cisco Transport Planner shelf layout are provisioned in CTC.
Stop. You have completed this procedure.
DLP-G693 Configuring the Amplifier Card
This task configures the optical parameters and
threshold values of the amplifier card.
Purpose
NoneTools/Equipment
DLP-G46 Log into CTCPrerequisite Procedures
As neededRequired/As Needed
Onsite or remoteOnsite/Remote
Provisioning or higherSecurity Level
Procedure
Step 1 Display the amplifier card in card view.
Step 2 Click the Provisioning > Card tabs.
Step 3 Select the working mode from the Card Working Mode drop-down list.
Step 4 Change to node view (single-shelf mode) or multishelf view (multishelf mode), then click the Provisioning
> WDM-ANS > Provisioning tabs.
Step 5 From the Selector area, select the amplifier slot. If the default parameters are present, continue with Step 6.
If not, click Add to add the Channel LOS Threshold, Amplifier Tilt, Power, and Amplifier Working Mode
Turning Up a Node
11
Turning Up a Node
DLP-G693 Configuring the Amplifier Card
