• noAuthNoPriv—Uses a username match for authentication.
• AuthNoPriv—Provides authentication based on the HMAC-MD5 or HMAC-SHA algorithms.
• AuthPriv—Provides authentication based on the HMAC-MD5 or HMAC-SHA algorithms. Provides
DES 56-bit encryption based on the CBC-DES (DES-56) standard, in addition to authentication.
• Target Address List—Select the proxy destination.
• Local User Name—Select the user name from the list of users.
When you configure SNMPv3 Proxy Forwarder Table automatically, the default_group is used on
the ENE. The default_group does not have write access. To enable write access and allow SNMP
sets, you need to edit the default_group on ENE.
Note
Step 5 Click OK to save the settings.
Step 6 Return to your originating procedure.
DLP-G504 Manually Configuring the SNMPv3 Proxy Trap Forwarder Table
This procedure creates an entry in the SNMPv3 Proxy
Trap Forwarder Table.
Purpose
NoneTools/Equipment
DLP-G46 Log into CTCPrerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
Provisioning or higherSecurity Level
Procedure
Step 1 In network view, click Provisioning > SNMPv3 tabs.
Step 2 In the SNMPv3 Proxy Server area, complete the following:
• From the GNE drop-down list, choose the GNE to be used as the SNMPv3 proxy server.
• Check the Enable IPv6 Target/Trap check box if the nodes and the NMS stations are on an IPv6
network.
Step 3 In the SNMPv3 Proxy Trap Forwarder Table area, click Manual Create.
Step 4 In the Manual Configuration of SNMPv3 Proxy Trap Forwarder dialog box, enter the following information:
• Remote Trap Source—Select the IP address from which the traps are sent. If the IP address is not listed,
enter the IP address manually.
Turning Up a Node
75
Turning Up a Node
DLP-G504 Manually Configuring the SNMPv3 Proxy Trap Forwarder Table
