NTP-G30 Installing the DWDM Cards
This procedure describes how to install the DWDM
multiplexer, demultiplexer, wavelength selective
switch, wavelength cross-connect, OADM, OSC,
PSM, and optical amplifier cards.
Purpose
• Cisco Transport Planner shelf layout
• The following C-band or L-band cards, as
required by your site plan:
• C-band: OPT-PRE, OPT-BST, OPT-BST-E,
32MUX-O, 40-MUX-C, 32DMX-O,
32DMX, 40-DMX-C, 40-DMX-CE,
32WSS, 40-WSS-C, 40-WSS-CE,
40-WXC-C, 80-WXC-C, 16-WXC-FS,
TDC-CC, TDC-FC, 40-SMR1-C,
40-SMR2-C, 17 SMR9 FS, 24 SMR9 FS,
34 SMR9 FS, SMR20 FS, SMR20 FS CV,
OPT-AMP-17-C, OPT-AMP-C,
OPT-RAMP-C, OPT-RAMP-CE,
OPT-EDFA-17, OPT-EDFA-24,
OPT-EDFA-35, EDRA-1-26, EDRA-1-35,
EDRA-2-26, EDRA-2-35, MMU,
4MD-xx.x, OSCM, OSC-CSM, and PSM
cards (as applicable)
• L-band: 32WSS-L, 32DMX-L,
OPT-BST-L, OPT-AMP-L, and PSM cards
(as applicable)
• The ONS 15454 NE defaults file if the node uses
custom NE defaults
Tools/Equipment
• NTP-G313 Installing and Configuring the TNC,
TNCE, TSC, or TSCE Card
• NTP-G139 Verifying Cisco Transport Planner
Reports and Files
• NTP-G143 Importing the Cisco Transport
Planner NE Update Configuration File
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
Provisioning or higherSecurity Level
