• Port ID—(Software provisioning view only) The port identifier shown in TL1 for the Position-2
connection.
• Port Label—The name of the physical port printed on the DWDM card’s front panel and shown in CTC
card view.
• P/F—Indicates whether you must create the connection manually in CTC. A Yes appearing in this column
means that you must create the connection manually.
Failure to create the required manual connections will prevent the node from turning up properly
Caution
Step 2 Return to your originating procedure (NTP).
NTP-G140InstallingFiber-OpticCablesBetweenTerminal,Hub,
or ROADM Nodes
This procedure routes fiber-optic cables from the
DWDM optical cards in a terminal, hub, or ROADM
node to the patch panel, and from the patch panel to
TXP, MXP, GE_XP, 10GE_XP, GE_XPE,
10GE_XPE, or ADM-10G cards.
Purpose
• See Step 1 for a list of equipment specific to each
node type.
• All node types require fiber-optic cables,
terminated with a single LC-type connector on
each end.
• Cisco Transport Planner Internal Connections
Report
Tools/Equipment
• In the Cisco ONS 15454 Hardware Installation
Guide
• “DLP-G28 Install the Fiber Patch-Panel
Tray”
• “DLP-G29 Install the Fiber-Storage Tray”
• NTP-G34 Installing Fiber-Optic Cables on
DWDM Cards and DCUs, on page 27
• DLP-G348 Using the Cisco Transport Planner
Shelf Layout Report
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
Turning Up a Node
31
