Step 7 Return to your originating procedure (NTP).
DLP-G790 Create a Static LMP Connection
This procedure creates a static LMP connection
between NCS 4000 (UNI-C) and NCS 2000 (UNI-N)
nodes for OCH unnumbered tunnel creation.
Purpose
NoneTools/Equipment
DLP-G46 Log into CTCPrerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
Provisioning or higherSecurity Level
Procedure
Step 1 In network view, click the Provisioning > LMP tabs.
Step 2 Click Create.
Step 3 In the LMP Creation pane, complete the following:
• From the Originating Node drop-down list, choose the required node or choose Add Router if the router
is not yet present in the network.
• Enter the IP address of the node in the Communication Channel field.
• From the Mode drop-down list, choose the required mode. The options available in the Local Interfaces
drop-down list changes based on the selected Mode.
• From the Local Interfaces drop-down list, choose an interface.
• From the Interfaces Configuration area, select the UnNumbered radio button for NCS 4000 node or
Numbered radio button for Cisco CRS.
Step 4 Click Next.
Step 5 In the LMP Termination pane, complete the following:
• Enter the IP address of the interface.
• From the Terminating node drop-down list, choose the required node.
• In the Rx Port Selection area, choose the required port from the Unit drop-down list.
• In the Tx Port Selection area, choose the required port from the Unit drop-down list.
Step 6 Click Next.
Step 7 In the Optical Parameters pane, enter the description, label and so on (optional) and click Next.
Turning Up a Node
78
Turning Up a Node
DLP-G790 Create a Static LMP Connection
