As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
To use Y-cable protection for GE_XP, 10GE_XP, GE_XPE, and 10GE_XPE cards, the cards must be
provisioned in 10GE MXP, 20GE MXP, or 10GE TXP mode. Y-cable protection cannot be used for GE_XP,
10GE_XP, GE_XPE, and 10GE_XPE cards that are provisioned in L2-over-DWDM mode.
Note
Procedure
Step 1 As needed, complete the DLP-G375 Installing Fiber-Optic Cables on the Y-Cable Modules in the FlexLayer
Shelf, on page 56.
Step 2 As needed, complete the DLP-G376 Installing Fiber-Optic Cables on the Y-Cable Modules in the Y-Cable
Module Tray, on page 58.
Stop. You have completed this procedure.
DLP-G375InstallingFiber-OpticCablesontheY-CableModulesintheFlexLayer
Shelf
This task installs fiber-optic cables from the TXP,
MXP, GE_XP, 10GE_XP, GE_XPE, 10GE_XPE,
AR_MXP, AR_XP, or AR_XPE cards to the Y-cable
modules installed in the FlexLayer shelves, and from
the Y-cable modules to the client devices.
Purpose
Fiber-optic cables
Cisco Transport Planner Internal Connections Report
Tools/Equipment
“DLP-G32 Install the Y-Cable Protection Modules in
the FlexLayer Shelf” in the Cisco ONS 15454
Hardware Installation Guide
NTP-G179 Installing the Transponder and Muxponder
Cards
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Turning Up a Node
56
Turning Up a Node
DLP-G375 Installing Fiber-Optic Cables on the Y-Cable Modules in the FlexLayer Shelf
