The following node types require the following
equipment. The cards and patch panels should already
be installed before you begin this procedure.
Terminal node:
• One 32DMX-O card
• One 32MUX-O card
• One standard patch panel tray
• Eight fiber-optic MPO cables: each MPO cable
is terminated on one end with one MPO
connector and on the other end with eight
LC-type connectors
Hub node:
• Two 32DMX-O cards
• Two 32MUX-O cards
• Two standard patch panel trays
• Sixteen fiber-optic MPO cables: each MPO cable
is terminated on one end with one MPO
connector and on the other end with eight
LC-type connectors
ROADM node:
• Two 32WSS cards
• Two 32DMX cards
• Two standard patch panel trays
• Sixteen fiber-optic MPO cables: each MPO cable
is terminated on one end with one MPO
connector and on the other end with eight
LC-type connectors
Tools/Equipment
NTP-G34 Installing Fiber-Optic Cables on DWDM
Cards and DCUs, on page 27
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Turning Up a Node
35
Turning Up a Node
DLP-G315 Installing Fiber-Optic Cables From the 32WSS/32DMX and 32MUX-O/32DMX-O Cards to the Standard Patch Panel Tray
