Monitor | Sessions | Protocols
15-37
VPN 3000 Concentrator Series User Guide
L2TP = Layer 2 Tunneling Protocol.
IPSec = Internet Protocol Security tunneling protocol (remote-access users).
HTTP = Hypertext Transfer Protocol (Web browser).
FTP = File Transfer Protocol.
Telnet = terminal emulation protocol.
SNMP = Simple Network Management Protocol.
TFTP = Trivial File Transfer Protocol.
Console = directly connected console; no protocol.
Debug/Telnet = debugging via Telnet (Cisco use only).
Debug/Console = debugging via console (Cisco use only).
L2TP/IPSec = L2TP over IPSec.
IPSec/LAN-to-LAN = IPSec LAN-to-LAN connection.
IPSec/NAT = IPSec through NAT (Network Address Translation).
Sessions
The number of active sessions using this protocol. The sum of this column equals the total number of
Active Sessions above.
Bar Graph
The percentage of sessions using this protocol relative to the total active sessions, as a horizontal bar
graph. Each segment of the bar in the column heading represents 25%.
Percentage
The percentage of sessions using this protocol relative to the total active sessions, as a number. The sum
of this column equals 100% (rounded).
