Configuring HTTP, HTTPS, and SSL parameters
1-19
VPN 3000 Concentrator Series User Guide
Configuring HTTP, HTTPS, and SSL parameters
HTTP, HTTPS, and SSL are enabled by default on the VPN Concentrator, and they are configured with
recommended parameters that should suit most administration tasks and security requirements.
To configure HTTP and HTTPS parameters, see the
Configuration | System | Management Protocols | HTTP/
HTTPS
screen.
To configure SSL parameters, see the
Configuration | System | Management Protocols | SSL screen.
Understanding the VPN Concentrator Manager window
The VPN Concentrator Manager window on your browser consists of three frames — top, left, and main
— and it provides helpful messages and tips as you move the mouse pointer over window items. The title
bar and status bar also provide useful information.
Figure 1-28: VPN Concentrator Manager window.
Title bar
The title bar at the top of the browser window includes the VPN Concentrator device name or IP address
in brackets; e.g.,
[10.10.104.7].
Status bar
The status bar at the bottom of the browser window displays explanatory messages for selected items
and Manager activity.
Title bar
Top frame
(Manager toolbar)
Left frame
(Table of contents)
Main frame
(Manager screen)
Status bar
