Eclipse | Upgrade Guide
Page 130
To upgrade the firmware file / application code of the E-QUE card (MK2):
1. Ensure that you have the following equipment:
Required equipment
Description / comments
Tera Term software
Tera Term (version 4.3 or later) must be
configured and operational. You can find the
Tera Term application on both of the Eclipse HX
9.0 upgrade media:
Software USB > SOFTWARE - EHX.xxx >
3rd_Party_Software > Teraterm
Drivers USB > ECLIPSE DRIVERS >
3rd_Party_Software > Teraterm
TFTP Server software
-
MVX Serial cable (CAB-
MVX-48Z)
See Figure 9-4: MVX-A16 serial cable (CAB-
MVX-48Z)
Ethernet crossover cable
-
Small reset tool
For example, a bent paper clip
Table 9-3: Required equipment
