5) The Serial port configuration dialog is displayed. Configure the serial port as
follows:
Com1
Note:
Change as required to match a COM port on the PC.
Table 6-5: Tera Term: Serial port configuration
Tip: The Tera Term application can be used for many of the Eclipse system
upgrade processes. You can save and recall the relevant com port settings in Tera
Term by selecting the Setup / Save or Restore settings options.
6) Connect the PC serial port to the RS232 port to the front of the Eclipse HX-PiCo
matrix.
7) Power off the matrix. To access the CPU, remove the lid from the matrix.
Remove power from the device first, to avoid
working with the system while it is live. Observe all
electrical shock hazard warning and precautions for
handling electrostatic sensitive devices.
8) Erase the old application code (firmware) from the CPU:
a. Place the CPU in TEST mode.
b.
c. Set the DIP switches on the CPU as follows:
