Single-point option
P/N 63674, Rev. 9 Page 83
For the hydraulic motor mount assembly, see Section 4.5.3 on page 90.
The PCU supplies air to the pneumatic feed box through the rotary union.
The single-point tool holder mounts to the saddle plate on the turning arm in place
of the milling head. See Section 4.5.2 on page 89.
The pneumatic feed box and adapter mounts on the end of the ball screw on the
turning arm.
The rotary union assembly mounts to the center of the rotary table and transmits
fluid to the hydraulic motor and air to the feed box. See Section 4.5.3 on page 90.
The air valve that cycles the feed box is also located here.
The emergency stop procedure is in Section 5.2.1 on page 98.
