Machine components
Page 14 CM6200 Operating Manual
2.2 MACHINE COMPONENTS
FIGURE 2-1. ID MOUNT COMPONENTS
MILLING HEAD
COUNTERWEIGHT
ASSEMBLY
HOSE TOWER
ENCODER GUARD
MACHINING ARM
HOIST RINGS
HOIST RINGS
DRAG BRAKE
ADJUSTABLE CHUCK ASSEMBLY
RADIAL TRAVEL BRAKE
AXIAL TRAVEL BRAKE
6
1
7
5
8
9
10
11
3
2
4
TABLE 2-2. ID MOUNT IDENTIFICATION
Number Component
1 Machining arm
2 Hose tower
3 Encoder guard
4 Counterweight assembly
5 Adjustable chuck assembly
6 Hoist rings
7 Drag brake
8 Milling head
9 Axial travel brake
10 Radial travel brake
11 Hoist rings
