P/N 63674, Rev. 9 Page 135
PARTS LIST
DESCRIPTIONPART No.QTYITEM
WASHER THRUST .75 OD X .312 ID X .031077011
FTG ELBOW 3/8 NPTM X 3/8 NPTF STREET 90 DEG1113212
FTG QUICK COUPLER 1/2B 1/2NPTF FEMALE AIR1320813
FTG NIPPLE 1/2NPTM CLOSE HEX147041
4
FTG QUICK COUPLER 1/2B 3/8 NPTM MALE AIR
1661515
HOSE ASSY 801 1/2 X 1/2 NPTMS ENDS X 180
3219616
SCREW M12 X 1.75 X 40mm SHCS
3521547
LABEL DIRECTION OVAL HANDLE BALL VALVE
3577218
VALVE BALL 1/2NPTF OVAL HANDLE3632819
FTG ADPTER 3/8 BSPP MALE X 3/8 NPTF52734110
TOOL HEAD ASSY FF LINE57781111
WASHER FIXTURING 21MM ID X 35MM OD X 3MM CASE HARDENED57888112
ARBOR GRINDING WHEEL CBN 10MM SHANK M8 THREAD62624113
ADAPTER SINGLE POINT TOOL HEAD TO MILLING ARM
62984114
SCREW M20 X 1.5 X 50MM SHCS
63018115
ASSY GRINDING ATTACHMENT
63063116
16
13
4
9
1
8
3
11
6
10
2
5
REMOVE FITTING TO
INSTALL ITEM 9
12
15
7
14
To Next Page
